| Specifications | |||
| C-120PRO | |||
Cutting range | Cutting range round | Ø35-Ø120mm | Ø1.38 -Ø4.72in |
Cutting range square | 35mm-95mm | 1.4in*3.7in | |
Shortest length of cut-off piece | 5mm | 0.2in | |
Shortest remnant length in automatic operation, possible only if the material has a perfect geometric surface | 85mm+a | 3.35in+a | |
Shortest remnant length individual cut | 30mm+a | 1.18in+a | |
| Dimensions and weight | Length | 2300mm | 90.6in |
| Width incl. chip conveyor | 2260mm | 88.97in | |
| Height | 2210mm | 87in | |
| Material support height | 925mm | 36.4in | |
Total weight | ≈3950kg | ≈8690lb | |
| Performance characteristics | Total connected load | 26kw | 34.6hp |
Power of saw motor | 18.5kw | 24.6hp | |
Hydraulic motor | 2.2kw | 3hp | |
Cutting speed infinitely variable with | 30-160r/min | ||
Saw feed speed | 0.3-30mm/s | 0.011-1.2in/s | |
| Rapid motion | 150mm/s | 5.9in/s | |
| Automatic material feed length, single stroke | 800mm | 31.49in | |
| Automatic material feed length, multiple stroke | 9999mm | 393.66in | |
| Saw blade diameter | Ø425mm | Ø16.73 | |
| Saw blade bores | Ø50mm | Ø1.96 | |
| Saw blade thickness | 2.7mm*2.25mm | 0.1in*0.08in | |
| Configuration Table | ||
| Category of configuration | Functional description | C-120PRO |
| EXTERIOR PROTECTION | CE standard fully enclosed protection | ● |
| SAW FEED SYSTEM | 45 degree servo feed | ● |
| 45 degree servo feed | × | |
| JLH-EHA | ● | |
| Saw Master | ○ | |
| ELECTRICS | CE Electrical Safety | ○ |
UL Electrical Safety | ● | |
| Main drive permanent magnet motor | ● | |
| HMI+Buttons | ● | |
Inverter | ● | |
Mistspray system (2L) | ● | |
| Dust collection device | ● | |
| Cutting pipe blast device | ● | |
| Cabinet air conditioner | ● | |
| LED working light | ● | |
| HYRAULICS | Automatic chip conveyor (spiral) | ● |
| Vise pressure regulator | ○ | |
| Motorized chip brush | ● | |
| Top clamp | ● | |
| Hydraulic cooling fan | ● | |
| Auto Lubrication device | × | |
| MATERIAL FEEDING | Roller type work table | ● |
| Simple Roller table | ● | |
| 0.8M Servo Feed | ○ | |
| 1.5M power output material table | ○ | |
| 2M Servo Power output material table | ○ | |
| Third vise | ○ | |
| 5,5m inclined powered magazine (rectangular material) | ○ | |
| 5,5m inclined powered magazine (round material) | ○ | |
| 5,5m belt infeed magazine (round material) | ● | |
| Other | Sawdust collection Cart 70 (L) | ● |
| Tool box (wire brush, levelling pads, spare paint) | ● | |
| Circular Saw blade | ○ | |
| Transport underframe for containers | ○ | |
| ● : Standard ○ : Optional × : Non-optional | ||
